I A P 2 0 2 3 . 0 0 1 - A F M / I R I S T E X A N I I P A G E | 123
FOR SIMULATION USE ONLY ā NOT A TRAINING AID
User Waypoints (USER WPT)
Depressing the USER WPT hard key allows pilots to view and change information
about waypoints in the user database.
For the purposes of this simulation, the data captured by the use of the Mark-On-
Top function is displayed in this window.
Key Window Action
USER WPT
NNWPT
W1 - Displays waypoints from the user database in
the format NNWPT where NN is the number of the
user waypoint and WPT is a fixed display.
The waypoints can be selected for viewing and
editing by entering the number (from 1-99) of the
desired user waypoints in this window.
Pressing W1 activates the W1 data entry mode and
display the active data entry triangle in the left-
most character location and permit the waypoint
number to be changed.
LAT,
LONG or
ELEV
W2 - Pressing W2 toggles between LAT, LONG, or
ELEV with each display starting in the second
character position.
When the selection is LAT or LONG, the window
also provides functionality for selecting the
latitude as N or S or the longitude as E or W.
The N or S (when the selection is latitude) or E or
W (when the selection is longitude) character is
displayed right justified.
N/S & E/W
W3 - The data displayed is the latitude value when
the W2 selection is LAT and pressing W3 toggles
between N or S, the data displayed is the longitude
value when the W2 selection is LONG and pressing
W3 toggles between E or W, the data displayed is
the elevation value when the W2 selection is ELEV
and W3 has no control functionality.
DDDMMMM,
DDMMMM or
NNNNN
W4 - The data corresponding to the selection in
window W3 is displayed in window W4, which is a
data entry window with no label.
The data displayed is the latitude value (a six-digit
number) when the W2 selection is LAT, the
