APPENDIX B. WPS TAGS 144
B.12 Images
Tag Description
%X|filename.bmp| Load and set a backdrop image for the WPS.
This image must be exactly the same size as
your LCD.
%P|filename.bmp| Load a Progress bar image for the WPS. Use
%pb tag to show the progress bar
%x|n|filename|x|y| Load and display an image
n: image ID (a-z and A-Z) for later referencing
in %xd
filename: filename relative to /.rockbox/
and including .bmp
x: x coordinate
y: y coordinate.
%xl|n|filename|x|y|[nimages|] Preload an image for later display (useful for
when your images are displayed condition-
ally)
n: image ID (a-z and A-Z) for later referencing
in %xd
filename: filename relative to /.rockbox/
and including .bmp
x: x coordinate
y: y coordinate.
nimages: (optional) number of sub-images
(tiled vertically, of the same height) contained
in the bitmap. Default is 1.
%xdn[i] Display a preloaded image
n: image ID (a-z and A-Z) as it was specified in
%x or %xl
i: (optional) number of the sub-image to dis-
play (a-z for 1-26 and A-Z for 27-52). By de-
fault the first (i.e. top most) sub-image will be
used.
Examples:
1. Load and display the image /.rockbox/bg.bmp with ID “a” at 37, 109:
%x|a|bg.bmp|37|109|
2. Load a bitmap strip containing 5 volume icon images (all the same size) with
image ID “M”, and then reference the individual sub-images in a conditional:
THE ROCKBOX MANUAL IRIVER H3XX
