46
SUMMARY: (left-wheel-stall?) PASS
SUMMARY: (drive-speed-ok? left forward) PASS
SUMMARY: (drive-speed-ok? right stopped) PASS
SUMMARY: (left-drive-current-ok?) PASS mA -86 min -150 max -75 mV 16031 degrees-C 37
SUMMARY: (left-drive-stall-current-ok?) PASS mA -804 min -850 max -700 mV 15919 degrees-C 37
SUMMARY: (right-wheel-stall?) PASS
SUMMARY: (drive-speed-ok? right forward) PASS
SUMMARY: (drive-speed-ok? left stopped) PASS
SUMMARY: (right-drive-current-ok?) PASS mA -90 min -150 max -75 mV 16031 degrees-C 37
SUMMARY: (right-drive-stall-current-ok?) PASS mA -788 min -850 max -700 mV15919 degrees-C 37
SUMMARY: (drive-speed-ok? left reverse) PASS
SUMMARY: (drive-speed-ok? right reverse) PASS
SUMMARY: (stasis-strong-signal?) PASS
SUMMARY: (main-brush-motor-stall?) PASS
SUMMARY: (main-brush-current-ok?) PASS mA -283 min -500 max -200 mV 15947degrees-C 37
SUMMARY: (main-brush-stall-current-ok?) PASS mA -1338 min -1400 max -1250 mV 15892 degrees-C 37
SUMMARY: (debris-right?) PASS
SUMMARY: (vacuum-current-ok?) PASS mA -143 min -230 max -50 mV 15947 degrees-C 37
SUMMARY: (side-brush-motor-stall?)
SUMMARY: (side-brush-current-ok?) PASS mA -95 min -120 max -30 mV 16031 degrees-C 37
SUMMARY: (side-brush-stall-current-ok?) PASS mA -456 min -550 max -400 mV 15975 degrees-C 37
SUMMARY: (int-charger-available?) PASS
SUMMARY: (int-charging-recovery-current-ok?) PASS mA 281 min 250 max 350 mV 16253 degrees-C 37
SUMMARY: (int-charging-current-ok?) PASS mA 1206 min 1000 max 1400 mV 16560 degrees-C 37
SUMMARY: (int-charging-trickle-current-ok?) PASS mA 58 min 40 max 70 mV 16170 degrees-C 37
SUMMARY: (int-charging-watchdog-current-ok?) PASS mA 0 min -20 max 20 mV 16142 degrees-C 37
SUMMARY: (ext-charger-available?) PASS
SUMMARY: (ext-charging-recovery-current-ok?) PASS mA 278 min 250 max 350 mV 16253 degrees-C 37
SUMMARY: (ext-charging-current-ok?) PASS mA 1162 min 1000 max 1400 mV 16532 degrees-C 37
SUMMARY: (ext-charging-trickle-current-ok?) PASS mA 60 min 40 max 70 mV 16170 degrees-C 37
SUMMARY: (bootloader-ok?) PASS
SUMMARY: (bbox-test-write-succeeded?) PASS
SUMMARY: (rf-system-functioning?) PASS
SUMMARY: (flash-file-system-ok?) PASS
SUMMARY: (calibration-data-stored?) disabled
SUMMARY: (factory-test-data-saved?) PASS
SUMMARY: END
SUMMARY OF ELECTRICAL CONSTANTS
Description Min Max Units Sensor
baseline battery current -300 -14 mA battery
left / right drive current -150 -75 mA wheel motor
left / right stall current -850 -700 mA wheel motor
main brush run current -500 -200 mA main brush
main brush stall current -1400 -1250 mA main brush
vacuum current -230 -50 mA battery
side brush run current -120 -30 mA side brush
side brush stall current -550 -440 mA side brush
Internal/external charging recovery current 250 350 mA battery
Internal/external charging current 1000 1400 mA battery
Internal/external charging trickle current 40 70 mA battery
