iRobot Roomba 570 - Spare Parts Replacement Instructions

64
Appendix D: Roomba Spare Parts Replacement Instructions
Roomba Spare Parts
Bottom Cover with 4 screws –
(US, EU, Sing, Japan, Korea)
Core Robot/Chassis Base Robot 3.0 –
(US, EU, Singapore, Japan, Korea)
Core Robot/Chassis Base Robot 3.4 –
(US, EU, Singapore, Japan, Korea)
Core Robot/Chassis Base Robot 3.5 –
(US, EU, Singapore, Japan, Korea)
Front Caster Wheel Module
Front Caster Wheel only
Right Wheel Module
Left Wheel Module
