ISOMAG ML 110 - DIMENSIONS (PA6 HOUSING); Compact Version Dimensions; Separate Version Dimensions; PA6 Housing Torques

6
DIMENSIONS (PA6 HOUSING)
COMPACT VERSION
SEPARATE VERSION
127
129
168
1
2
4
78
CABLE GLAND
COVER SCREW
IF2 CAP
TORQUES
To guarantee the housing’s IP degree the following torques are required:
 cover screws: 0.5Nm
 cable glands: 4Nm (in reference conditions)
 IF2 cap: 4Nm
Weight: 0.5kg
Weight: 1kg
