ITech IT6000D Series User Manual

Technical Specification
Parameter IT6015D-80-450
Standard Interface
Standard: USB, CAN, LAN, VCP; optional: GPIB, analog card (in-
cludes RS232), fiber optic socket
Isolation ( output to ground)
500V
Working Temperature
0～50℃
Dimension ( mm) 483mm(W)*801.61mm(D)*151.3mm(H)
Weight( net)
40KG
Note: 1. Models without emergency stop module (i.e. AC contactor not included), other AC in-
put voltage ranges are required for customization. Models without emergency stop module and
assembled to the cabinet, with AC input voltage in the range of 198~264V, need to be custom-
ized while derating by 50%. Models with emergency stop module (including AC contactor) only
support 380VAC±10% for standard AC input voltage, 480VAC±10% voltage is required for
customization.
6.1.2 300V
6.1.2.1 IT6006D-300-75
Parameter IT6006D-300-75
Rated value
Output Voltage
0～300V
( 0 ℃-50 ℃) Output Current
0～75A
Output Power
0～6kW
Line Regulation Voltage
≤0.01%FS
±(％of Output+Offset)
Current ≤0.05%FS
Load Regulation Voltage
≤0.02%S
±(％of Output+Offset)
Current ≤0.05%FS
Setup Resolution
Voltage
0.01V
Current 0.01A
Power 0.001kW
Read Back Resolution
Voltage
0.01V
Current 0.01A
Power 0.001kW
Setup Accuracy Voltage
≤0.02% + 0.02%FS
( within 12 months, 25℃
±5℃)
Current ≤0.1% + 0.1%FS
±(％of Output+Offset)
Power ≤0.5% + 0.5%FS
Copyright © Itech Electronic Co., Ltd.
132
