Quick Reference
3U Model
1 Power On/Off switch
2 Vacuum fluorescent display
(VFD)
3 Function and composite keys
4 Numeric and composite keys
5 Up, down, left, and right cursor navigation
keys and Enter key
6 Push-on knob
7 Vent hole
8 USB storage device connection port
1.3 Keyboard Introduction
The keyboard introduction of IT6000D series High power Programmable DC
Power Supply is shown as follows.
Keys Description
[On/Off] Turn the power supply output on or off. When lit, indicates
that the output is enabled or on.
[V-set] Set the output voltage value
Copyright © Itech Electronic Co., Ltd.
4
