ITech IT6000D Series User Manual

Technical Specification
Parameter IT6006D-800-25
Standard Interface
Standard: USB, CAN, LAN, VCP; optional: GPIB, analog card (in-
cludes RS232), fiber optic socket
Isolation ( output to ground)
1500V
Working Temperature
0～50℃
Dimension ( mm) 483mm(W)*801.61mm(D)*151.3mm(H)
Weight( net)
20KG
Note:
1. Models without emergency stop module (i.e. AC contactor not included), other AC input volt-
age ranges are required for customization. Models without emergency stop module and as-
sembled to the cabinet, with AC input voltage in the range of 198~264V, need to be customized
while derating by 50%. Models with emergency stop module (including AC contactor) only sup-
port 380VAC±10% for standard AC input voltage, 480VAC±10% voltage is required for
customization.
6.1.4.2 IT6012D-800-50
Parameter IT6012D-800-50
Rated value
Output Voltage
0～800V
( 0 ℃-50 ℃) Output Current
0～50A
Output Power
0～12kW
Line Regulation Voltage
≤0.01%FS
±(％of Output+Offset)
Current ≤0.05%FS
Load Regulation Voltage
≤0.02%FS
±(％of Output+Offset)
Current ≤0.05%FS
Setup Resolution
Voltage
0.01V
Current 0.01A
Power 0.001kW
Read Back Resolution
Voltage
0.01V
Current 0.01A
Power 0.001kW
Setup Accuracy Voltage
≤0.02% + 0.02%FS
( within 12 months, 25℃
±5℃)
Current ≤0.1% + 0.1%FS
±(％of Output+Offset)
Power ≤0.5% + 0.5%FS
Read Back Accuracy Voltage
≤0.02% + 0.02%FS
Copyright © Itech Electronic Co., Ltd.
147
