Power Supply Function
Sweep: Sweep wave
The fields included in the .csv template file are explained as follows:
Model
Device model, keep the default settings without
modification.
Firmware
Version
Firmware version number, keep the default settings
without modification.
Serial Number
Device serial number, keep the default settings with-
out modification.
File Type
File type, keep the default settings without
modification.
Waveform Type
Waveform type, keep the default settings without
modification.
Amp Unit Peak-to-peak unit, CV priority is set to V, CC priority
is set to A.
Offset Unit Offset value unit, CV priority is set to V, CC priority is
set to A.
Time Unit Time unit, S.
Frequency Unit Frequency unit, Hz.
Mode Indicates the power supply working mode. The CV
priority is set to CV, and the CC priority is set to CC.
Repeat Repeat times, the setting range is 1~65535.
Amp Peak-to-peak
Offset Offset value
Start Frequency Start frequency
End Frequency Stop frequency
Step DwelH Total running time
Step time Single-step pulse width. Single-step pulse width and
single-step repetition times can be set by selecting
one of them.
Step Repeat The number of repetitions of a single step. Single-
step pulse width and single-step repetition times can
be set by selecting one of them.
Copyright © Itech Electronic Co., Ltd.
75
