Power Supply Function

Charge Time Set the battery charging time.

Cut Off Voltage Battery test cut-off voltage

Cut Off Current

Battery test cut-off current

Cut Off Capacity Battery test cut-off capacity

1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-

ter the function menu.

2. Use knob or Up/Down key to select 2.BATTERY: Off and press [Enter].

The interface is displayed as follows:

FUNCTION BATTERY

Run Edit

3. Press the Left/Right key to select Edit and press [Enter].

4. Set the charging voltage (Charge V), charging current (Charge I) and the

other parameters, and then press [Enter] to confirm.

After the parameter setting is completed, the interface returns to the Battery

function main interface and displays as follows:

FUNCTION BATTERY

Run Edit

5. Press the Left/Right key to select Run and press [Enter].

The instrument will enter the battery test mode and wait for the battery test

to be triggered.

6. Turn on the [On/Off].

This product supports Sense anti-reverse function. If you reverse the

Sense cables, the VFD will display a negative voltage value, and you can-

not turn on the output at this time. It can only be turned on after the cables

are properly connected.

7. Based on the selected trigger method, perform the trigger operation.

The trigger method of the battery test is consistent with the trigger method

of the List function, that is, the List trigger source is also effective for the

Battery function.
