Quick Reference
Flag Function
Description
Flag Function Description
SRQ Indicates that the
internal status re-
quest event occurs.
Trig The instrument is in a state
of waiting for a trigger.
CW The power supply is
in a state of con-
stant power output.
- -
1.7 Configuration Menu Function
This section gives an overview of the configuration menu of the IT6000C series
power supply.
The procedures to operate the configuration menu are as follows.
1. Press the composite keys [Shift]+[V-set] (Config) on the front panel to enter
the configuration menu.
The VFD shows configuration menu items and each menu item is marked
with a number. The user can use up and down keys or knob to scroll pages
to view the other menu items.
2. Press [Enter] to select the desired menu item.
Enter the parameter setting interface of this menu item.
3. After finishing the menu setting, press [Enter] key to save the setting.
Press [Esc] key to return to the previous menu level.
The descriptions of configuration menu of the power supply are listed in the ta-
ble below.
Config Configuration menu of the power supply
Mode
CC/CV priority mode setting
CV
Constant voltage loop priority mode
Speed= High/Low
Loop response
speed setting:
high speed /
low speed
Copyright © Itech Electronic Co., Ltd.
10
