Quick Reference
CC
Constant current loop priority mode
Speed= High/Low
Loop response
speed setting:
high speed /
low speed
V-Rise Time/I-Rise Time
= 0.001s
Displays the voltage or current rise time
setting according to the selected priority
mode. If CC priority mode is selected,
the parameter setting of I-Rise Time will
be displayed here.
V-Fall Time/I-Fall Time =
0.001s
Displays the voltage or current fall time
setting according to the selected priority
mode. If CC priority mode is selected,
the parameter setting of I-Fall Time will
be displayed here.
Output Res
Set the internal resistance of the power
supply. This parameter needs to be set
only when Mode is set to CV.
On Delay Set the delay time to turn on the output.
Off Delay Set the delay time to turn off the output.
1.8 System Menu Function
This Chapter offers a general introduction of system menus, allowing users to
have a preliminary understanding of system functions of this IT6000C series.
The steps of the system menu function are as follows:
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
At this point, the VFD screen displays the system menu items. Each menu
item has a numbering identifier. The user can press Up and Down buttons or
use the knob for scrolling display of other menu items.
2. Press [Enter] on a menu interface to enter the setting interface.
3. After the menu items are set, press [Enter] again to save the modified
contents.
Copyright © Itech Electronic Co., Ltd.
11
