Quick Reference

500V 800V 1500V 2250V Height

(with bare

machines

overlap-

ped)

Height

(consti-

tuting

cabinet)

IT6018C-500-

IT6018C-800-

IT6018C-1500-

IT6018C-

2250-20

IT6018C-500-

90S

IT6018C-800-

60S

IT6018C-1500-

30S

IT6018C-

2250-20S

Naming rules for each series of model are as follows: IT 6XXXC-YYY-ZZZ,

wherein, XXX means rated power; YYY means rated voltage; and ZZZ

means rated current. The IT6018C-500-90S, IT6018C-800-60S, IT6018C-

1500-30S, and IT6018C-2250-20S are slave models, and the specifications

are the same as the corresponding master models.

As a bipolar power supply, this series can output and absorb electric energy.

The current and power input capacity is same as the output capacity. For ex-

ample, the maximum rated value of the output power of the IT6018C-500-90

model is 18,000W, and the maximum rated value of input power is also

18,000W.

1.2 Front-Panel Overview

For the IT6000C series Bi-directional Programmable DC Power Supply, all front

panels of the 3U model are the same, and the operation panels of other models

are the same as those of the 3U model. The following is the front panel sche-

matic of the 3U model.
