ITRON 100W-R User Manual

Initializing, Programming, and Connecting the ERT Module
TDC-0951-005 100W-R and 100WP-R Datalogging ERT Module Installation Guide 9
Proprietary and Confidential
Connecting the 100W-R to a Remote Meter Register
Connect the wires from the 100W-R ERT module to the register screw terminals according to the following
table.
Register Manufacturer
100W-R wire color
Brown (data)
Gray (power/clock)
Yellow (ground)
Register screw color designator
Elster AMCO Invision
R
GRN
BLK
Elster AMCO Scancoder
R
GRN
BLK
Elster AMCO evoQ4 (Q4000)
R
White
BLK
Hersey Translator
GRN
R
BLK
Badger ADE
GRN
R
BLK
Sensus ECR (all variants)
GRN
R
BLK
Sensus ICE
GRN
R
BLK
Metron Famier
GRN
R
BLK
Itron (Actaris) Coder
GRN
R
BLK
Neptune ProRead
E-Coder
ARB-V
R
B
G
Performance ETR
GRN
R
BLK
SevernTrent SM700 SmartMeter
(Sensus Protocol)
GRN
R
BLK
