Installing 40W and 50W ERT Modules PUB-0126-001 4/04
5-6
Place the ERT module mounting
bracket on the work surface with its
inside up.
01552x
Place the ERT module on the
mounting bracket the way shown
here, with the
wires
in the remote mounting bracket
cable exit notch.
5-7
5-3
01551
To Next Page
