Commissioning protocol
6 720 645 504 (2011/04) en
106
22 Commissioning protocol
Information about the installation:
Customer/responsible for installation:
Installer/person in charge of commissioning:
Heat pump: _____________________________ Serial number: ___________________________________
Commissioning date: ____________________ Date of manufacture: _______________________
Type of collector: ____________________________ Number of circuits: ___________ Length per circuit:
_____________ m
Additional heat (Oil/Gas/Power):
_________________________
Output: __________ kW
Product / Type: _______________________________
Hot water heater, volume: ____________ litres Product / Type: _______________________________
Expansion vessel, volume:
Heating system: __________ litres
Collector circuit: ____________ litres
Product / Type: _______________________________
Product / Type: _______________________________
External circulation pumps:
G1 Circuit 1
G1 Circuit 2
G1 Circuit 3
G1 Circuit 4
G6 Hot water circulation
Product / Type: _______________________________
Product / Type: _______________________________
Product / Type: _______________________________
Product / Type: _______________________________
Product / Type: _______________________________
Type of heating system (Radiator/Underfloor): Circuit 1 __________________________ Circuit 2 ___________________________
Circuit 3 ________________________ Circuit 4 _________________________
External motor valves:
Mixing valve Additional heat Q71
Mixing valve Circuit 2 Q11
Mixing valve Circuit 3 Q11
Mixing valve Circuit 4 Q11
Product / Type: _______________________________
Product / Type: _______________________________
Product / Type: _______________________________
Product / Type: _______________________________
Other components in the installation:
Unscrew the transport locking devices installed in the heat pump ( 5.5 ). Check that the pipes in the heat pump
have not been displaced during transportation and lie opposite to the chassis and that the bottom plate is free.
Check of collector circuit installation:
Collector circuit system connected according to system solution, Figure: ________, in the handbook and correctly
insulated against insulation
Remark:
Collector circuit filled with water mixed with antifreeze type______________________ mixture_________%
Vented Freezing limit_____°C checked with refractometer. Pressure filled to__________bar.
Tab. 198 Commissioning protocol
