IVT Greenline HC 22 User Manual

Technical information
6 720 645 504 (2011/04) en
14
8 Technical information
8.1 Component parts
8.1.1 HC 22 - 33
Fig. 9
1 Type plate
2 Collector circuit pump
3 Heat carrier pump
4 Low pressure switch
5 Condenser
6 Compressor (1 and 2)
7 Evaporator
8 Sight glass
9 High pressure switch
10 Expansion valve
11 3-way valve
12 Drying filter
13 Transport locking devices (2) and Vibration dampers (2)
6 720 614 967-5.1I
8
5
5
3
3
8
11
12
12
2
4
2
6
9
4
6
9
10
13
1
7
7
10
13
