Lifting the heat pump
6 720 645 504 (2011/04) en
7
4 Lifting the heat pump
Remove the packaging and the transport pallet from the
heat pump. Dismantle also the front and side plates
before lifting the heat pump into the building.
Fig. 3 HC22-33 with lifting belts
1 HC 22-33 with lifting belt on opposite sides
2 Attach the lifting belts to the heat pump according to the
figure
DANGER: Personal injuries may occur. The
heat pump weighs between 330 and 360 kg.
B Never lift the heat pump by hand.
x 2
1
2
6 720 645 504-02.1I
