Settings
6 720 645 504 (2011/04) en
74
> External input circuit 2, 3...
>> Invert input
B Select Yes if the input signal is to be reversed (i.e.
activated with open contact).
>> Block heating at tripped underfloor temperature
limiter
>> Block heating
>> Room temperature
B Set the room temperature that should apply in the
event of enabled external control.
B Value > 0 °C enables the function.
The highest temperature is used if temperature changes
have been set for a certain circuit at several external
inputs.
16.6 Installer
This section includes:
• General
• Heat pump capacity
• Connected I/O boards
• Operating times and consumptions
• Temperatures
• Inputs
• Outputs
• Circulation pumps
• Screed drying
16.6.1 General
> Anti-seizure mode
>> Day of the week
>> Start time
B Set date and time for anti-seizure operation of vital
parts of the installation.
Anti-seizure mode ensures that vital components do
not become clogged during periods when they are not
used.
>> Minimum outdoor temperature
B Set the outdoor temperature under which anti-seizure
run may not be run.
Anti-seizure mode operates differently in summer and in
winter. This enables the duration of the anti-seizure
operation to be reduced. Furthermore, during anti-
seizure operation the entire system does not need to be
switched off in winter.
Factory setting No
Alternative No/Yes
Tab. 125 Invert input
Factory setting No
Alternative No/Yes
Tab. 126 Blocking
Factory setting No
Alternative No/Yes
Tab. 127 Blocking
Factory setting No (0.0 °C)
Lowest value 10.0 °C
Highest value 35.0 °C
Tab. 128 Room temperature
Factory setting Wednesday
Alternative Monday-Sunday
Tab. 129 Anti-seizure day
Factory setting 12:00
Alternative 0:00 - 23:00
Tab. 130 Anti-seizure start time
Factory setting 2.0 °C
Lowest value -20.0 °C
Highest value 20.0 °C
Tab. 131 Minimum outdoor temperature
