This manual gives you all the information necessary to install the heat pump
and electric boiler. The guide is divided into several parts in the order in
which installation and commissioning must be carried out.
Before staring the installation:
The heat pump may be temporarily tilted with the compressor
downwards. It must never laid down or transported horizontally. (See
Transport and storage)
Check that the plumbing connections in the heat pump and the electric
boiler are intact and have not shaken loose during transport.
Before the commissioning the heating system must be filled up and
completely vented.
Important information to the installer
Checklist
The following checklist will give you a general description of how the installa-
tion should be carried out.
1. Position the heat pump on a solid base.
2. Install the incoming and outgoing pipes for the heat pump.
3. Install the drainage pipe for the heat pump.
4. Fit the particle filter.
5 Install the incoming and outgoing pipes for the electric boiler.
6 Install the waste water hose for the electric boiler.
7. Connect the heat pump and electric boiler.
8. Connect the heat pump and the electric boiler to the heating system.
9. Install the outdoor sensor and room sensor if used.
10. Connect the CANbus wiring between the heat pump and 290 A/W.
11. Fill and vent the heating system before commissioning.
12. Connect the standard enclosure (safety switch included), any earth-fault
breaker and any power guard..
13. Connect the heat pump and electric boiler to the power supply.
14. Commission the heating installation by making all the necessary settings
on the control panel.
15. Check the heating installation after commissioning.
Warning
For reasons of safety the main power
supply must be disconnected before
working on the heat pump and elec-
tric boiler.
!
Note
Only qualifi ed installers may carry
out the installation. The installer must
follow applicable rules and regula-
tions and recommendations from the
supplier.
Important information to the installer / Checklist
