9
General
3-way
valve
3-way
valve
Heating
system
Heating
system
T1 Flow sensor
T2 Outdoor sensor
T3 Hot water sensor
T5 Room sensor
T6 Sensor compressor temperature
T8 Sensor heat transfer fluid out
T9 Sensor heat transfer fluid in
T10 Sensor condenser temperature
T11 Sensor refrigerant temperature
evaporator
T12 Sensor air temperature evaporator
Location of the temperature sensors
Optima
290 A/W
