J-Tech Digital JTD-669 - EDID Interface Management; EDID Information Display; User EDID Editing; Applying EDID Profiles to Inputs

24
EDID Interface:
1. Input：00>>Input1 | 00 - 16: EDID number | Input 1 - 4: HDMI Input Port 1 - 4
2. Output：00 - 03: Default EDID | 04 - 07: User EDID | 08 - 11: Copy EDID | 12 - 15:
Input EDID | 16: Temp EDID
00
4K60 444-LPCM: 2.0, HDR:HLG
01
4K60 420-LPCM: 2.0, HDR:None
02 4K30 444-LPCM: 2.0, HDR:None 03 1080P60 444-LPCM: 2.0,
HDR:None
04
User1
05
User2
06 User3 07 User3
08
Copy HDMI Out 1
09
Copy HDMI Out 2
10
Copy HDMI Out 3
11
Copy HDMI Out 4
12
Copy Input 1
13
Copy Input 2
14
Copy Input 3
15
Copy Input 4
16
Default is empty. Requires EDID to be saved to device to take effect. *Doesn’t
support power-off memory
1. EDID Information Field: This field shows EDID info.
Ex: Click “00>>Input1” or “00:Default1” to show resolution, audio format, audio
channels, HDR and serial number.
2. Edit User EDID: Click “Edit User EDID”. Choose EDID profile from the drop-down
menu on “EDID Edit Page” and then save to User 1-4 profiles.
Operation：
1）Apply Default2 EDID Profile to HDMI Input 1: Click “00>>Input1” and then click
“01:Default2”.
2）Save HDMI Out 1 EDID to User1 Profile: Choose ”Default1” in “EDID Edit
Page” and then choose “User1” and click “Set” to finish.
