J-Tech Digital JTD-669 User Manual

5
2
3
Panel Descriptions
IR Receiver Sensor
Output 1 - 4: Short press to choose output (press again to cancel); long press to
choose all outputs (long press again to cancel).
Input 1 - 4: Short press to choose input (user must choose output first); long press to
choose one input for all outputs.
PRESET: Access Presets
UP: Navigate Up through menu
LOCK: Long press to enable button lock (long press to unlock). *Note – All buttons are
non-functional except for ‘Lock’ button when lock function is enabled.
MENU: Access main menu or return to the previous menu interface
DOWN: Navigate Down through menu
ENTER: Short press to confirm selection
LCD Screen
*Note: LCD screen will enter power saving mode if a selection has not been made within
60 seconds.
1
4
5
6
7
8
9
10
Front Panel

J-Tech Digital JTD-669 Specifications

General

Brand	J-Tech Digital
Model	JTD-669
Category	Switch
Language	English
