20
2.3.4 OPERATING THE SYSTEM USING SMS COMMANDS
SMS commands can control individual sections and programmable outputs
just like keypad segment buttons. The form of text message to operate
the system is: CODE_COMMAND. The actual commands are predefined (SET/
UNSET) with an additional numeric parameter which identifies a specific section.
One SMS can control multiple sections at the same time. In this case, added
numbers in the command define sections.
Example of an SMS command used to set sections 2 and 4.
CODE_SET_2_4
The commands to control the programmable outputs can be programmed
by a system installer. For example, you may choose BLINDS DOWN as your
command to close the blinds on your windows. It is also possible to configure
the system not to require a code before a command. In such case the command is simply automatically
identified when the system recognizes the user’s phone number from which the SMS was sent.
Configuration is done by a service technician.
2.3.5 OPERATING THE SYSTEM REMOTELY USING A COMPUTER (J-LINK)
The JABLOTRON 100
+
system can be operated remotely using a computer
with an installed J-Link software.
It can be downloaded from the “Downloads” section
of the www.jablotron.com website or it can be found in the control panel’s
SD card. The registration code of the security system (a 15-digit code) and
the telephone number of its SIM card is required to connect to the system
remotely the first time. Remote access is initiated by clicking on “Internet”
in the main menu.
After establishing the connection with the control panel, the operating
is the same as when connecter locally via USB cable.
2.3.6 CONTROLLING THE PROGRAMMABLE OUTPUTS (PG)
2.3.6.1 KEYPAD SEGMENT
A PG output switches on by pressing the right button of the segment and switches off by pressing
the left button. If the output is configured as a pulse output, it is switched off according to the pre-set time.
PG control may or may not be stored in the control panel’s event memory. Configuration is done
by a service technician.
Authorization is/is not demanded based on the system configuration.
2.3.6.2 USER KEYPAD AUTHORIZATION
It is possible to activate a PG output just by user authorization (entering a code or using an RIFD tag).
The PG output must be configured to activate from a designated keypad.
2.3.6.3 FROM THE MENU OF THE KEYPAD WITH AN LCD DISPLAY
After user authorization the programmable outputs can be controlled from
the menu of the keypad with an LCD display. The user has access
to programmable outputs depending on the user’s permissions.
Control from the keypad menu
a Authorization by a valid code or an RFID chip.
a Enter the menu by pressing ENTER.
a PG Control → ENTER.
a Select the desired PG group using arrows (1–32), (33–64), (65–96),
(97–128) → ENTER.
2. OPERATING THE JABLOTRON 100
+
SYSTEM
