6 2. OPERATING THE JABLOTRON 100
+
SYSTEM
The types of access modules and their combinations:
When unsetting the alarm using the segment buttons,
user authorization is always required. When setting the alarm
and controlling automated processes using the segment
buttons, user authorization is optional for each segment.
RFID card reader – allows control
of the system using segments and user
authorization using contactless method
(RFID card/tag).
Keypad with a card reader – the user
can control the system using segments
and authorization, either by entering
a code or the contactless method (RFID
card/tag), or a combination of both for
higher security.
Keypad with an LCD display and
a card reader – the user can control
the system using segments and authori-
zation, using either a code, the contact-
less method (RFID card/tag), both code
and card/tag for higher security,
or by authorizing and using the options
available on the keypad’s LCD display.
Continuous yellow
PARTIALLY SET
Flashes red
ALARM /
ALARM MEMORY
Continuous green
EVERYTHING OK
Flashes green
CONTROL
Flashes green 2x each 2 s
MAINTANENCE
Continuous yellow
FAULT
Flashes yellow
UNSUCCESSFUL SETTING
CARD READER / KEYPAD
Continuous red
SET / ON
Flashes red
ALARM /
ALARM MEMORY
Continuous green
UNSET / OFF
Flashes green
ENTRY DELAY
