INSTRUCTIONS
INSTALLATION
ELECTRICAL POWER
CONNECTIONS
Electrical and grounding conductors must comply with the applicable portions of the
National Electric Code ANSI/NFPA 70 (latest edition) and/or other electrical codes.
The data plate is located at the left front side of the dishmachine. Refer to the data
plate for machine operating requirements, machine voltage, total amperage, and serial
number.
Remove the back panel to install the incoming power lines. This will require removing
the screw at the bottom of the back panel with a phillips screwdriver. Remove the
back panel and set aside. Install 3/4” conduit into the pre-punched holes in the back
of the control box. Route power wires and connect to power block and grounding lug.
Install the service wires (L1and L2) to the appropriate terminals as they are marked
on the terminal block. Install the grounding wire into the lug provided. It is recom-
mended that “DE-OX” or another similar anti-oxidation agent be used on all power
connections.
Ensure that the power button is in the off position and apply power to dishmachine.
Check the incoming power at the terminal block and ensure it corresponds with the
voltage listed on the data plate. If not, contact a qualied service agency to examine
the problem. Do not run dishmachine if voltage is too high or too low. Shut off the
service breaker and advise all proper personnel of the location of the breaker and
any problems. Replace the control box cover and tighten-down the screws.
This is a commercial dishmachine and reaches temperatures that can exceed those
generated by a residential machine. Therefore, any surrounding countertops, cabinets,
ooring material, and suboor material must be designed and/or selected with these
higher temperatures in mind.
NOTE: Any damage to surrounding area that is caused by heat and/or moisture to
materials that are not recommended for higher temperatures will not be covered under
warranty or by the manufacturer.
The temperature setpoints on this unit have been set at the factory. They should
only be adjusted by an authorized service agent.
Disconnect electrical
power supplies and tag
out in accordance with
appropriate procedures
and codes at the
disconnect switch to
indicate the circuit is being
serviced.
TEMPERATURE
SETPOINTS
SURROUNDING
AREA
VOLTAGE CHECK
i
