Jackson DISHSTAR HT-E - Electrical Requirements

07610-004-43-79-Q
6
All electrical ratings provided in this manual are for reference
only. Always refer to machine data plate to get exact electrical
information for this machine. All electrical work performed on
machines should be done in accordance with applicable local,
state, territorial, and national codes. Work should only be
performed by qualied electricians and authorized service agents.
Amperage loads for motors and heaters are indicated on machine
data plate.
The electrical congurations are as follows:
Available Electrical Characteristics:
• 208 V, 60 Hz, Single-phase
• 230 V, 60 Hz, Single-phase
• 460 V, 60 Hz, Three-phase
Available Wash Motors:
• 1 HP
Available Wash Tank Heaters:
• 3.3 kW (208 V)/4.0 kW (230 V)
• 3.7 kW (460 V)
Available Rinse Tank Heaters:
• 4.1 kW (208 V)/5.2 kW (230 V)
• 5.0 kW (460 V)
DishStar HT-E/HT-E-SEER
Electrical Characteristics
VOLTS 208 230 460
PHASE 1 1 3
FREQ 60 60 60
WASH
MOTOR
AMPS
5.0 A 5.0 A 2.0 A
WASH
HEATER
AMPS
15.7 A 17.4 A 4.6 A
RINSE
HEATER
AMPS
19.7 A 22.6 A 6.3 A
TOTAL
LOAD
24.7 A* 27.6 A* 8.3 A*
MCA 25.9 A 28.8 A 8.8 A
MOP 30 A 30 A 15 A
NOTICE
i
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
*The DishStar
®
HT-E is designed so the heaters never run simultaneously. Total Load is based on the higher of the two loads.
