47
07610-004-43-79-Q
PLUMBING OPTIONS
PARTS
PRESSURE REGULATING VALVE (PRV) OPTION
Water Arrestor, 1/2”
06685-100-05-00
Tee, 1/2” x 1/2” x 1/2”
04730-211-27-00
Nipple, 1/2” NPT, Brass
04730-207-15-00
SHOCK ABSORBER (WATER ARRESTOR) OPTION
Pressure Regulating Valve, 1/2”
04820-100-04-07
Water Arrestor Repair Kit
(Plunger & O-ring)
06401-003-06-23
Replacement Cartridge
(inspect at least every 6 months)
04730-003-28-04
SPS System
04730-003-28-03
Replacement Test Strip
(Not Shown)
06401-003-28-06
Must be installed vertically. The provided
bracket is secured to the wall. Observe
proper inlet/outlet water directions (ow
directions are molded into the top of the
head). Line pressure should be released
before changing cartridges. Machine
should be delimed before installation.
SCALE PREVENTION SYSTEM (SPS) OPTION
HT-E-SEER has a water arrestor as
standard equipment. See the HT-E-SEER
Plumbing page.
HT-E-SEER has a PRV as standard
equipment. See the HT-E-SEER
Plumbing page.
To Next Page
