33
07610-004-43-79-Q
CHEMICAL FEEDER PUMPS, 208-230 V
PARTS
10
11
1
2
4
3
6
7
8
9
5
ITEM QTY DESCRIPTION PART NUMBER
1 1 Motor, 14 RPM 04320-011-63-33
2 2 Pump Housing, Clear 04320-004-59-41
3 2 Washer, Thrust, Peri-pump 04320-004-75-85
4 4 Screw, 8-32 x 3/8" Phillips 05305-111-37-07
5 4 Screw, 8-32 x 1/2" Phillips 05305-111-37-06
6 2 Roller, Black Dot 04320-111-65-27
7 1 Tube, Squeeze, 14 RPM Peri-pump 04320-004-92-38
8 2 Pump Cover, Clear 04320-004-59-45
9 6 Screw, 6-32 x 3/4" Phillips 05305-011-37-05
10 1 Motor, 38 RPM 04320-004-99-36
11 1 Tube, Squeeze, 36 RPM Peri-pump 05700-003-22-89
Part numbers for complete
assemblies on previous page.
208-230 V machines with serial
numbers before 22E406186 have
dierent pumps. Click here to open
earlier manual.
