07610-004-43-79-Q
32
CONTROL PANEL, 208/230 V
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 3 Contactor, 30 A, 240 VAC 05945-002-74-20
2 1 I/O Module 05945-004-44-63
3 2 End Bracket, Terminal 05999-004-90-66
4 5 Separator, Terminal Block 05999-004-90-67
5 16 Terminal Block, Single Level 05999-004-90-68
6 16 Tag, Marking 05999-004-90-72
7 1 Power Supply 05950-004-81-79
8* 1 Peri-pump Assembly, 14 RPM 05700-004-71-63
9 1 Din Rail, 5 3/4" 05700-021-72-75
10 4 P-clamp, 1/4" ID 05975-002-61-42
11 1 Bushing, 1 1/8" 05975-210-08-00
12 1 Bracket, Control Panel 05700-004-96-19
13 6 Screw, 10-32 x 1/2" 05305-002-80-88
14 9 Fastener, 10-32 05340-111-58-10
15 1 Fuse, Time-delay 8 A, 250 V 05920-004-85-54
16 5 Nut, Plated 6-32 05340-118-04-00
17 3 Screw, 6-32 x 3/8" 05305-002-25-91
18 2 Screw, 10-32 x 1" 05305-002-19-42
19* 1 Peri-pump Assembly, 38 RPM 05700-005-00-29
20 2 Jumper Bars, 4-Pole 05999-004-41-80
21 2 Jumper Bars, 3-Pole 05999-004-90-71
22 1 Jumper Bars, 2-Pole 05999-004-41-79
23 1 Screw, 10-32 x 1/2" 05305-011-39-36
24 1 Decal, Ground 09905-011-86-86
25 1 Fuser Holder, One Only 05920-002-42-13
26 1 Relay, 10 A, 240 VAC 05945-111-89-75
27 6 Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00
28 2 Screw, 6-32 x 1/2" 05305-004-23-63
29 2 Sti󰀨ener, Chemical Tube 05700-002-66-49
30 1 Chemical Port Assembly 05700-004-30-86
31 1 Tubing, Red, 1/4" x 120" 05700-011-37-15
32 1 Tubing, Red, 1/4" x 80" 05700-011-37-14
33 1 Tubing, Clear, 1/8" x 120" 05700-002-76-14
34 1 Tubing, Clear, 1/8" x 48" 05700-002-76-15
*See next section for peri-pump components.
