The manufacturer highly recommends that any maintenance and repairs not specically
discussed in this manual only be performed by qualied service personnel. Performing
maintenance on the machine may void a warranty.
By following operating and cleaning instructions in this manual, users should get
the most e󰀩cient results from the machine. As a reminder, here are some steps to
ensure the machine is used properly:
1. Ensure water temperatures match those listed on machine data plate (on front-
left of machine).
2. Remove as much soil as possible from ware before loading into racks.
3. Ensure strainers are in place, laying at in tub, and free of soil and debris before
operating machine. To clean strainers, wipe out with a rag and rinse under a
faucet. For stubborn debris, a toothpick can be used. Do not beat strainers on
waste cans; once bent, they will not work properly.
4. Ensure all wash and rinse arms are secure in machine before operating.
PREVENTATIVE MAINTENANCE
MAINTENANCE
PREVENTATIVE
MAINTENANCE
i
XXXXXXXXX
ATTENSION:SECONNECTERAUNMINIMUM D’ALIMENTATION 30 AMPERES
DELAI FUSIBLE DE TYPE NON-TEMPS OU LAPROTECTION CONTRE LES SURINTENSITES.
NOTE: WASHAND RINSE HEATER DO NOT OPERATE
AT THE SAME TIME. ELECTRICALLOADS BASED ON WASH
MOTORAND RINSE HEATER (HIGHESTAMP DRAW)
CAUTION: IF THIS MACHINE IS CONNECTED TOACIRCUIT PROTECTED BYFUSES,
USEONLY 30A NON-TIMEDELAYFUSE OR O VERCURRENT
PROTECTION.
SERIALNO.:
60Hz 1 PH 2 WIRE
5.0A
230 VOLT
1 HP
MODEL:DISHSTAR HT-E
Made in the USA
Jackson WWS , Inc
6209 N US HWY25E
Gray, KY40734
(606) 523-9795
09905-004-42-87D
155°F
180°F
110°F
80 SEC
5.0A
17.4A
4 KW
15.9A3.3 KW
26.7A24.7A
WASH MOTOR
RINSE HEATER
TOTALLOAD
OPERATING PARAMETERS
MINIMUM WASH TEMP
MINIMUM RINSE TEMP
MIN. INCOMING WATER TEMP
WASH CYCLE TIME
RINSE CYCLE TIME
WATER FLOW PRESSURE
208 VOLT
9 SEC
1 HP
10PSI
WASH HEATER
19.7A
5 KW
21.7A
4.1 KW
MINIMUM CIRCUITAMPACITY
MAXIMUM OVERCURRENT PROTECTION
@208 VOLTS: 26.0AMPS
@230 VOLTS: 28.0AMPS
@208 VOLTS: 30AMPS
@230 VOLTS: 30AMPS
4000897
Conforms to ULStd 921
Conforms to CSA
Std C22.2 No.168
Intertek
4000897
Conforms to NSF Std 3
CAUTION! Do NOT beat
strainers to remove
soil and debris!
!
CAUTION
