Jackson DISHSTAR HT-E - Page 51

07610-004-43-79-Q
44
ITEM QTY DESCRIPTION PART NUMBER
1 1 Wash Arm Assembly 05700-021-39-23
2 1 Motor Support 05700-004-40-61
3 1 Wash Halo 05700-004-42-21
4 2 Pipe Clamp 05700-000-35-06
5 5 Wash Arm End-cap 05700-003-31-59
6 2 Screw, 1/4-20 x 1/2" 05307-011-36-96
7 4 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
8 1 Manifold Gasket 05330-002-34-77
9 1 Wash Hub 05700-004-43-04
10 1 Wash Motor See Motors page.
11 1 Discharge Hose, 7/8" x 8" 05700-004-43-76
12 1 Hose, 1 1/4" x 2 3/4" 05700-011-44-48
13 4 Clamp, 1 1/16" to 2" 04730-719-18-00
14 1 Hose, Manifold Bottom 05700-001-22-92
15 3 Clamp, 13/16" to 1 1/2" 04730-719-06-09
16 2 Hosebarb, 90-Degree, 3/4" x 1" 04730-011-65-87
17
1 Drain Valve Assembly, 208/230 V 04730-003-33-64
1 Drain Valve Assembly, 115 V (for 460 V Machine) 04730-003-34-60
18
1 Bracket, Drain Valve Support, 208/230 V 05700-004-35-85
1 Bracket, Drain Valve Support, 460 V 05700-004-42-01
19 1 Drain Hose 04720-004-32-00
WASH
PARTS
