SEER SYSTEM
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1
Motor, Fan, 208/230 V
Motor, Fan, 115 V (for 460 V Machine)
05999-004-63-31
05999-004-64-71
2 1 Wheel, Blower 05999-004-59-13
3 1 Bracket, Bearing Boot 05700-004-50-94
4 1 Bushing and Housing Assembly 03120-004-50-88
5 5 Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00
6 1 Bracket, Motor Adjustment 05700-004-58-81
7 2 Grommet, Push-in, 3/4" ID 05330-004-59-14
8 2 Bracket, Enclosure Filler Plate 05700-004-58-93
9 1 Diversion Plate 05700-004-59-04
10 1 Upper Shield 05700-004-58-98
11 1 Heat Exchanger, 3/8" Tubes 04420-004-58-96
12 12 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
13 8 Screw, 6-32 x 1/2" 05305-004-23-63
14 1 Condenser Assembly 05700-004-58-94
15 2 Bolt, 1/4-20 x 1/2" 05305-274-02-00
16 1 Plumbing, SEER Inlet 05700-004-60-46
17 1 Bracket, Bearing Hard Stop 05700-004-67-53
18 1 Lower Shield 05700-004-63-04
19 1 Spacer, 1/2" OD 1/4" ID Nylon, Black 03120-004-95-13
20 1 Gasket, Exchanger to Tub 05330-004-59-16
Machines with serial numbers before 19G376587 have an older version of the SEER System. Click here to
open manual with the older version.
