PARTS
TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED)
24
ITEM QTY DESCRIPTION PART NUMBER
1 1 Control Box Weldment 05700-003-30-14
2 1 Timer Bracket 05700-003-02-08
3 2 Lock Nut 6-32 05310-373-03-00
4* 2 Heater Contactor 05945-109-01-69
5 1 Terminal Block 05940-011-48-27
6 17 Lock Nut 10-24 05310-373-01-00
7 1 Contactor, Wash Motor 05945-002-74-20
8 1 Relay 05945-111-47-51
1 Relay (415V, 3PH, 5 Wire Only) 05945-111-89-75
9 1 Light, Green 05945-111-44-43
10 1 Light, Red 05945-111-44-45
11 1 Temperature Gauge, Wash 96" Lead 06685-111-68-49
12 1 Temperature Gauge, Rinse 48" Lead 06685-111-68-48
13 1 Light, Yellow 05945-111-44-44
14 1 Decal, Wash 150°F Min 09905-002-97-61
15 1 Decal, Rinse 180°F Min 09905-002-97-62
16 1 Ground Lug 05940-200-76-00
17 1 Bracket, Liquid Level Control Board 05700-002-13-22
18 1 Liquid Level Control Board 06680-200-08-21
19 6 Tricnut, 6-32 05340-118-04-00
20 3 Screw, 6-32 x 5/8" 05305-011-39-85
21 3 Plug, 1/2" 05975-011-47-81
22 2 Grommet, 7/8" Split 05975-200-40-00
23 1 Bushing Snap 05975-210-02-00
24 1 Clamp, Hose .25-.312 05975-002-61-43
25 1 Decal, Warning-Disconnect Power 09905-100-75-93
26 1 Cover, Top Mount Control Box 05700-002-23-03
27 1 Decal, Control Box 09905-003-97-38
28 4 Lockwasher, Int. Tooth #10 05311-273-03-00
29 4 Screw, 10-32 x 3/8" Phillips Truss Head 05305-173-12-00
30 1 Decal, Copper Conductors 09905-011-47-35
31 1 Decal, Ground 09905-011-86-86
32 1 Decal, L1, L2 09905-002-78-67
33 1 Bracket, Fuse Strip 05700-002-42-03
To Next Page
