Jackson TempStar Series Installation, Operation & Service Manual

PARTS
25
ITEM QTY DESCRIPTION PART NUMBER
34 1 Fuse Holder, 6 Pole 05920-002-42-13
35 2 Screw, 6-32 x 3/8" with Ext. Tooth Washer 05305-002-25-91
36 1 Decal, Dispenser Connection 09905-003-34-09
37 1 Timer, Universal 05945-003-33-09
Timer, Universal Fused (Alternate) 05945-003-75-23
38 4 Locknut, 10-32 05310-373-02-00
39 4 Screw 10-32 x 1" 05305-002-19-42
40 1 Switch, Rotary Selector 05930-003-97-61
41 1 Switch, Operation 05930-301-53-00
42 1 Switch, Power 05930-011-49-55
43* 1 Overload, TK-ONY (460 Volt Unit Only) 05945-002-65-02
44* 1 Motor Contactor, SC-03Y (460 Volt Unit Only) 05945-002-65-00
45* 1 Din Rail 2-3/4" (460 Volt Unit Only) 05700-001-84-65
TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED)
*For a 460V Unit, replace item 4 with items 43, 44 & 45.

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
