SIDE MOUNT UNIVERSAL TIMER CONTROL BOX ASSEMBLY (CONTINUED)
PARTS
27
ITEM QTY DESCRIPTION PART NUMBER
1 1 Bracket, Electrical Box Mounting 05700-002-18-48
2 9 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00
3 9 Washer, 1/4"-20 I.D. S/S 05311-174-01-00
4 1 Control Box Weldment, Right Hand 05700-002-06-48
1 Control Box Weldment, Left Hand 05700-002-23-08
5
2
1
Contactor, 4 Pole, 220V, 1 Phase
No Booster, Steam Models and LT
05945-109-01-69
6 4 Screw, 10-32 x 1/2" Phillips Pan Head with Washer 05305-002-32-37
7 1 Liquid Level Control 06680-200-08-21
8 3 Screw, 6-32 x 5/8" 05305-011-39-85
9 1 Thermometer, 48 Lead, Wash 06685-111-68-48
1 Decal, Wash 150°F 09905-002-97-61
1 Decal, 120°F Wash/Rinse (not shown) (LT only) 09905-002-82-46
10 1 Relay, 240V, 50/60Hz, Top Mount 05945-002-47-74
11 8 Screw, 6-32 x 3/8" SEMS with External Tooth Washer 05305-002-25-91
12 1 Decal, Control Box Gauge 09905-002-10-69
13 1 Thermometer, 96 Lead Rinse 06685-111-68-49
1 Decal, Rinse 180°F 09905-002-97-62
1 Decal, 120°F Wash/Rinse (not shown) (LT only) 09905-002-82-46
14 1 Timer, Universal 05945-003-75-23
15 1 Timer, Bracket 05700-003-02-08
6 Holder, Keystone 05940-002-21-87
1 Keying Plug 05940-003-11-66
2 Connector 05940-003-11-65
16 1 Contactor, 2 Pole, 220V, 20 Amp (208-230V Unit only) 05945-002-74-20
17 1
Timer, Cycle Delay (not used with Universal Timer or LT) (not
shown)
05945-002-13-78
18 1 Terminal Block, 3 Pole 05940-011-48-27
19 1 Decal, L1, L2, L3 09905-101-12-66
20 1 Decal, Copper Conductors 09905-011-47-35
21 4 Locknut, 10-24 S/S Hex with Nylon Insert 05310-373-01-00
22 1 Wire Lug 05740-200-76-00
23 1 Decal, Ground 09905-011-86-86
24 1 Holder, Fuse 05920-401-03-14
To Next Page
