Jackson TempStar Series Installation, Operation & Service Manual

PARTS
SIDE MOUNT CONTROL BOX ASSEMBLY (CONTINUED)
28
ITEM QTY DESCRIPTION PART NUMBER
25 1 Cover, Control Box Weldment 05700-002-06-52
Cover, Control Box Weldment (not shown) (LT) 05700-004-22-50
26 4 Bolt, 10-32 x 1/2" Slotted Truss 05305-173-04-00
27 1 Switch, Rotary Selector - Not on LT 05930-003-97-61
28 1 Switch, Operation 05930-301-53-00
29 1 Decal, Control Box Cover 09905-003-97-39
1 Decal, Control Box Cover (LT ONLY) (not shown) 09905-004-22-33
30 1 Light, Red 05945-504-07-18
31 1 Light, Green Indicator 05945-504-08-18
32 1 Light, Amber 05945-504-06-18
33 1 Cover, Dielectric Control Panel (not shown) 05700-021-50-89
34 1 Contactor, 2 Pole, 220V, 20 Amp (460V Unit Only) 05945-002-65-00
35 1 Overload (460V Unit Only) 05945-002-65-01
36 1 Switch, Power 05930-011-49-55

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
