Jackson TempStar Series Installation, Operation & Service Manual

PARTS
35
TUB ASSEMBLY (CONTINUED)
ITEM QTY DESCRIPTION PART NUMBER
1 1 Tub Weldment 05700-002-12-59
2 1 Rack Assembly 05700-002-01-00
3 2 Bulk Head Plug 04730-609-05-00
4 1 See Page Entitled “Wash Motors” N/A
5 1 Gasket 05700-111-35-03
6 1 O-ring 05330-400-05-00
7 4 Bolt, Hex 3/8”-16 x 1 1/4" Long 05305-276-10-00
8 1 Lower Wash Manifold Weldment 05700-031-46-00
9 1 Suction Strain Weldment 05700-001-22-23
10 1 Suction Strain Bracket 05700-001-22-24
11 8 Locknut, 1/4"-20 with Nylon Insert 05310-374-02-00
12 1 Strainer Weldment 05700-021-50-07
13 1 Wash Overow Weldment 05700-001-25-69
* 1 Support, Ball Stop Lift 05700-002-91-55
* 1 Ball Stop Lift 05700-002-91-54
* 1 Shim, Overow Support 05700-002-96-48
14 1 Overow Support Bracket 05700-001-27-55
15 1 O-Ring 05330-400-05-00
16 2 Clamp, Hose 1 5/16” to 2 1/4” 04730-719-01-37
17 1 Discharge Hose 05700-011-88-24
18 1 Nipple 05700-021-34-84
19 1 Pump Support Bracket Assembly 05700-002-00-46
20 1 Clamp, Hose 5 5/8" to 6" 04730-011-34-90
21 1 Connector, 1/2” 90B 05975-111-01-00
22 4 Nut, 3/8"-16 S/S Hex 05310-276-01-00
23 4 Lockwasher 3/8” 05311-276-01-00
24 1
See Page Entitled “Wash Heaters/Rinse Heaters”
See page 27 to order phase conversion kits for the heater.
N/A
25 1 Probe, High Water 06680-200-02-68
26 5 Locknut, 6-32 with Nylon Insert 05310-373-03-00
27 4 Lockwasher, 5/16", S/S, Split 05311-275-01-00
28 4 Nut, Hex, 5/16"-18, S/S 05310-275-01-00
29 4 Locknut, 10-24 with Nylon Insert 05310-373-01-00

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
