en-16
SPECIFICATIONS 4
FAIRWAY 305 405
Model: V1505T-E2B-RANUK-1
Type: Vertical, water-cooled, 4-cycle diesel engine
Number of Cylinders 4
Bore and Stroke 74mm x 78.4mm
Total Volume 1498cm³
Combustion Chamber Spherical type (E-TVCS)
Intake System Turbo Charged
Gross Intermittent Power 34.7kW @ 3000rpm
Maximum Speed: 3000 ± 50 RPM (No load)
Idle Speed: 1500 ± 100 RPM
Firing order 1-3-4-2
Direction of Rotation Counter-clockwise (Viewed from Flywheel side)
Injection Pump Bosch MD type mini pump
Injection Pressure 13.73 MPa (140kgf/cm²)
Injection Timing (Before T.D.C.) 18°
Compression Ratio 23.5:1
Fuel: No. 2-D Diesel fuel (ASTM D975)
Lubrication (API Class) Above CD grade
Oil Sump Capacity: 6.4 litres
Dimensions (length x width x height) 591.3mm x 439.2mm x 613.7mm
Dry Weight 114kg
Starter Cell starter (with glow plug)
Starter motor 12V, 1.4kW
Generator 12V, 360w
