en-35
6CONTROLS
6.2.A. ENGINE PREHEAT INDICATOR LAMP ________________________________
The green lamp Illuminates when the ignition switch is
turned clockwise to the Preheat position. When the lamp
turns off, the engine is ready to start.
6.2.B. ENGINE TEMPERATURE GAUGE ____________________________________
Indicates the temperature of the engine.
6.2.C. HYDRAULIC OIL OVER TEMPERATURE WARNING LAMP ________________
The red lamp Illuminates when the temperature of the
hydraulic oil reaches a preset level. If the lamp
illuminates, stop the vehicle and disengage the cutting
units. Apply the parking brake and stop the engine.
To Next Page
