8 MAINTENANCE & LUBRICATION
B
8.2 ENGINE LUBRICATION ________________________________________________
Check Engine Oil Level
Check the engine oil level before you start or at least five
minutes after you stop the engine.
(a) Park the machine on level ground,
remove the dipstick (D), clean with a
cloth and replace in position.
(b) Remove the dipstick (D) again and
check the oil level. The oil must be
between the two level indicators (E) on
the dipstick.
Change Engine Oil
(a) Start the engine to increase the temperature, then
turn off the engine. Remove oil drain plug from the
bottom of the crankcase and clean with a cloth.
(b) Drain engine oil into a container.
(c) Replace the drain plug (A) and fill the engine with the
correct quantity and grade of oil through the filler (B).
Change Engine Oil Filter
(a) Remove the single-unit cartridge (C).
(b) Let the engine oil flow into a container.
(c) Clean area on the crankcase.
(d) Apply a thin layer of oil to cartridge gasket before you
install the filter.
(e) Only use your hand to tighten the filter.
(f) Check for oil leaks around the cartridge gasket after
the engine is started.
CAUTION
The Engine Oil Can Damage Your Skin. Use
Gloves When You Use Engine Oil. If Engine Oil
Touches Your Skin, Clean The Area
Immediately.
CAUTION
Discard Used Engine Oil As Shown In Local
Regulations
