Jacobsen LF557 4WD - Page 126

126
LIGHTWEIGHT FAIRWAY MOWER
61.1
4WD 7 Gang Schematic
Serial No. All
CBT2 CA
LB LARB RA
CP
WP
CG
WG
T1
.56 ci .56 ci .56 ci .56 ci
Gear
Pump
Rear
Reel
Valve
Front
Reel
Valve
1167
psi
1167
psi
LR Reel Motor
RR Reel Motor
*
*
1167
psi
LF Reel Motor
*
1167
psi
C Reel Motor
*
1167
psi
RF Reel Motor
*
Reel
Diag.
Rear
Reel
Diag.
Wing
Reel
Diag.
Strg.
Diag.
10
Micron
25 psi
Crack
Bypass
25 psi
Crack
Bypass
100
Mesh
Screen
Return
Filter
Oil
Cooler
B
A
C
D
E
F
G
H
J
* Reel Motor Displacement
LF550 .72 ci
LF570 1.01 ci
1167
psi
RW Reel Motor
*
1167
psi
LW Reel Motor
*
A
B
P
G
T
3625
psi
3625
psi
315 psi
2.81 ci
Tow
Valve
Reverse
Diag.
Forward
Diag
2800
RPM
A
B
Traction
Pump
EDC
SOL6
SOL5
SOL2 SOL1
SOL16 SOL15SOL14 SOL13
