136
LIGHTWEIGHT FAIRWAY MOWER
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
B1 NS Battery
C1 See 44.1 4293091 Board, 100 µF 16V Capacitor Included in Mower Harness
C2 4341395 Board, Adaptive Throttle Resistor Included in T4F/S5 LDU Harness
CB1 See 44.1 361439 50 Amp Circuit Breaker (Alternator)
CR1 See 44.1 4193880 Main Power Relay
CR2 See 44.1 4193880 Glow Plug Relay
CR3 See 44.1 4193880 Starter Relay
F1 See 44.1 5003280 10 Amp Fuse T4F/S5 Only, Included in Harness
F2 See 44.1 5003283 25 Amp Fuse T4F/S5 Only, Included in Harness
F3 See 44.1 5003278 5 Amp Fuse T4F/S5 Only, Included in Harness
F4 See 44.1 5003278 5 Amp Fuse T4F/S5 Only, Included in Harness
F5 See 44.1 4312246 15 Amp Mini Fuse Included in Harness
F6 See 44.1 4312213 10 Amp Mini Fuse Included in Harness
F7 See 44.1 5003282 20 Amp Fuse Included in Mower Controller
F8 See 44.1 5003282 20 Amp Fuse Included in Mower Controller
F9 5003282 20 Amp Fuse Included in 7 Gang Harness
F10 See 44.1 2 Amp Mini Fuse Included in Harness
L1 See 44.1 4123183 Left Headlight Bulb
L2 See 44.1 4123183 Right Headlight Bulb
M1 Not Shown 4198229 Starter Motor Included in Engine
M2 See 18.1 4272290 Fuel Pump
M3 Not Shown 4297196 Supply Pump Included in Engine
M4 Air Ride Seat Compressor Optional Grammer Seat
R1 Not Shown 4289844 Glow Plug Included in Engine
SOL1 See 53.1 4200060 Rear Backlap Solenoid
SOL2 See 53.1 4135552 Rear Mow Solenoid
SOL3 See 55.1 4135552 Lift Solenoid
SOL4 See 55.1 4135552 Lower Solenoid
SOL5 See 53.1 4200060 Front Backlap Solenoid
SOL6 See 53.1 4135552 Front Mow Solenoid
SOL7 4224140 Traction Pump EDC Solenoid
SOL8 See 52.1 4134532 Brake Solenoid
SOL9 See 56.1 4134530 Center Lift/Lower Enable Solenoid
SOL10 See 56.1 4134532 Front Lift/Lower Enable Solenoid
SOL11 See 56.1 4134530 R Wing Lift/Lower Enable Solenoid
SOL12 See 56.1 4134530 L Wing Lift/Lower Enable Solenoid
SOL13 See 57.1 4135552 R Wing Mow Solenoid
SOL14 See 57.1 4135552 R Wing Backlap Solenoid
SOL15 See 57.1 4135552 L Wing Mow Solenoid
SOL16 See 57.1 4135552 L Wing Backlap Solenoid
SOL17 Not Shown Fuel Solenoid (Included in Engine) Tier 4 Interim Option Only
SW1 556419 Hydraulic Filter Switch
SW2 See 42.1 4125831 Reel Proximity Switch
SW3 See 6.1 4326362 Adaptive Throttle Rotary Switch Tier 4 Final/Stage 5 Option Only
To Next Page
