Jacobsen LF557 4WD - Page 140

140
12
Coolant Temperature
(U7)
Cam Sensor
(U3)
Crank Sensor
(U2)
Intake Throttle Valve
(U6)
EGR Valve
(U8)
Rail Pressure Sensor
(U4)
Supply Pump
(M3)
12
1
123
2 3
1
2 3
123 456
4 3 21
1
2
3
4
5
6
7
8
9
1314151617
1819202122
2324252627
2829303132
3334353637
3839404142
10
11
12
J6
Connects to Mower Harness
Terminal Identification is from open (Not Wire) end of connector
LIGHTWEIGHT FAIRWAY MOWER
62.1 Connector Terminal Identification
Tier 4 Final / Stage 5 Engine Harness 4297202 (Included with Engine)
Serial No. All
