Jacobsen LF557 4WD - Page 141

141
123
Diff Pressure Sensor
(U12)
DPF Temp T0 Sensor
(U11)
DPF Temp T2 Sensor
(U9)
DPF Temp T1 Sensor
(U10)
Fuel Injector #1
(U13)
12
Fuel Injector #2
(U14)
12
Fuel Injector #3
(U15)
12
Fuel Injector #4
(U16)
12
21 21 21
J8
Connects to Mower Harness
J10
Connects to Mower Harness
1
9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
1
7
2
8
3
9
4
10
5
11
6
12
Injector Harness 4297203 (Included with Engine)
DPF Harness 4297204 (Included with Engine)
Terminal Identification is from open (Not Wire) end of connector
LIGHTWEIGHT FAIRWAY MOWER
62.1 Connector Terminal Identification
Tier 4 Final / Stage 5 Injector Harness 4297203 and DPF Harness 4297204
Serial No. All
