142
LIGHTWEIGHT FAIRWAY MOWER
62.1 Connector Terminal Identification
Tier 4 Interim Mower Harness 4301097
Serial No. All
Optional Seat Switch
(SW5A)
Rear Backlap Solenoid (SOL1)
Rear Mow Solenoid (SOL2)
Lift Solenoid (SOL3)
Lower Solenoid (SOL4)
Front Backlap Solenoid (SOL5)
Front Mow Solenoid (SOL6)
EDC Solenoid (SOL7)
Brake Solenoid (SOL8)
Reel Prox. Switch (SW2)
Seat Switch (SW5)
Alternator
(U22)
Air Ride Seat
(M4)
Fuel Pump
(M2)
Head Lights
(L1 and L2)
BA
BABA
21
1
Starter
(M1)
1
2
1
2
1
2
3
6
5
4
J11 CAN
C
BA
654
3 21
To Armrest Harness
(J15)
Fuel Solenoid (K15)
HP
CR3
CR2
87 87A 30
85
86
87 87A 30
85
86
12
12
12
F6
F5
F10
Terminal Identification is from open (Not Wire) end of connector
Traction Pedal (U5)
To 7 Gang Harness (J16)
