LIGHTWEIGHT FAIRWAY MOWER
62.1 Connector Terminal Identification
Tier 4 Interim Mower Harness 4301097 (Continued)
Serial No. All
MCU J3 (U18)
(Grey)
MCU J1 (U18)
(Black)
MCU J2 (U18)
(Green)
123456
121110987
123456
121110987
123456
121110987
Terminal Identification is from open (Not Wire) end of connector
