Jacobsen LF557 4WD - Page 144

144
LIGHTWEIGHT FAIRWAY MOWER
62.1 Connector Terminal Identification
Armrest Harnesses 4301099 (T4F/Stage 5) and 4329452 (T4I)
Serial No. All
Horn Switch (SW9) (Red)
Mow Switch (SW10) (Grey)
Light Switch (SW12) (Green)
Parking Brake Switch (SW13) (Black)
Cruise Control Switch (SW14) (White)
7
8
4
1
5
2
6
3
Adaptive Throttle Switch (SW3)
Tier 4 Final / Stage 5 Armrest Harness 4301099
9
6
5
4
7
10
3
2
1
8
LDU J12 (U21)
(Black)
LDU J11 (U21)
(Green)
123456
121110987
123456
121110987
Ignition Switch (SW8)
Joystick (SW11)
To Mower Harness
(J15)
To Mower Harness
(J9)
1
2
3
6
5
4456
12
34
123
Horn Switch (SW9) (Red)
Mow Switch (SW10) (Grey)
Light Switch (SW12) (Green)
Parking Brake Switch (SW13) (Black)
Cruise Control Switch (SW14) (White)
7
8
4
1
5
2
6
3
LDU J12 (U21)
(Black)
LDU J11 (U21)
(Green)
123456
121110987
123456
121110987
Ignition Switch (SW8)
Joystick (SW11)
To Mower Harness
(J15)
1
2
3
6
5
4 456
123
Tier 4 Interim Armrest Harness 4329452
Terminal Identication is from open (Not Wire) end of connector
Resistor Card Socket (C1)
ABCDEF
