Jacobsen Tri King Parts & Maintenance Manual

73
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
1002944 1 Tube, Steering Valve to Filter
2 2811063 1 Tube, Steering Valve to Pump
3 364221 1 Clamp
4 400114 1 Screw, 1/4-20 x 1-1/4” Hex Head
5 452004 2 Flat Washer, 1/4
6 444708 1 Locknut, 1/4-20 Center
7 1002942 1 Left Steering Hose
8 1002941 1 Right Steering Hose
9 354080 2 Hose Clamp
10 446136 1 Lockwasher, 5/16 Hvy
11 443106 1 Nut, 5/16-18 Hex
12 473142 4 Nylon Tie
13 339974 1 Adapter Straight
14 340057 2 Adapter, 90°
15 340061 4 Adapter, 90°
16 1002940 1 Lift Cylinder Hose
17 1001500 1 Lift Cylinder Hose
18 1001502 1 Lift Valve Hose
19 1001501 1 Lift Valve Hose
20 339910 1 O-Ring, #10 ORFS
21 340088 1 Adapter, 90°
22 1001356 1 Lift Valve
5001419 1 • Seal Kit
23 122759 1 Hydraulic Cylinder
554331 1 • Seal Kit
24 339909 3 O-Ring, #6 ORFS
