ADJUSTMENTS 3
13
3.10 PARKING BRAKE__________________________________________________________
1. Check l inkage cables and pivots t o e nsure they a re
operating smoothly.
2. Park the m ower on a 30 % slope ( 16.7°) nea r th e
bottom of the hill, with the front of the mower facing
downhill. E ngage t he par king brake a nd s top th e
engine.
a. The mower s hould s tay o n t he hill without
creeping.
b. If t he brakes do no t h old, s tart t he engine,
disengage the brake, and dr ive to the bo ttom of
the hill.
3. With par king b rake di sengaged, tur n ad justing k nob
in a c lockwise di rection, applying a nd releasing
brake ev ery quarter tur n, u ntil a defi nite “ snap ov er
center” action is achieved.
4. Repeat the test on the hill if required.
Note: Over adjustment causes hard lever action, but
does not increase brake efficiency.
3.11 REAR LIFT ARM ___________________________________________________________
1. Rear li ft arm pos ition is properly adj usted when the
rear m ower bumpers a re p utting slight pressure
against the underside of the foot rests.
2. Disconnect li ft c hain (T) fr om c rank and adj ust b all
joint (U) as required.
Figure 3I
3.12 DOWN PRESSURE_________________________________________________________
1. Place mowers in the Fixed Mode (Section 3.18) and
lower the mowers onto a sc ale, capable of weighing
250 lb . ( 113 kg). The r ear roller of t he m ower m ust
rest on the scale.
2. To adj ust pr essure o n r ear mo wer l oosen n uts ( V)
and adjust to obtain the desired pressure.
3. To adj ust pr essure on front mowers, loosen nu t ( W)
and ad just b olt ( X). M inimum t hread eng agement
should be 1/2 in. (13 mm).
4. To maintain a co nsistent hei ght of cut, the dow n
pressure s hould be ad justed e venly o n a ll thr ee
mowers.
5. Jacobsen, recommends the mo wer wei ght for
Floating Mode at 6 0 lb. (27 kg), and for Fixed Mode
at 90 lb. (41 kg).
Figure 3J
Figure 3K
CAUTION
DO NOT disengage the brakes with the engine off.
